- 1080P PTZ IR IP CAMERA
-
-
-
For 20X ZOOM Camera
1．HI3516CV2000 main chipset
2．high sensitivity and high SNR Micro Megapixel SONY 323 CMOS sensor
3.20X optical ZOOM with 4.7mm-97mm zoom lens
4．support 1080p(1920*1080) real-time output
5．support Three stream viewing at the same time
6．support two-way voice talk back function
7．support mobile phone remote view, compatible with many smartphone operating platform
8．Support WIFI / 802.11 b/g/n wireless network(Option)
9．support ONVIF protocol
10．Support RTSP protocol, using VLC monitor directly
11．built-in SD card slot, Max 128Gb,timer capture
12. Support Audio input and output
13．Support alarm pictures to send E-mail
14．support alarm pictures to FTP server
15．support timer capture pictures to SD Card and FTP server
16．support static IP, also support dynamic IP(DHCP)
17．Support manufacture’s DDNS and third party DDNS
18．support P2P Plug and Play
19．support motion detection alarm(can set multiple regions and sensitivity) and sensor alarm
20．can set multiple alarm period, and support alarm linkage
21．support Max 12 users browsing at the same time (first stream: 4 users, sub stream: 4 users, Three Stream:4 users)
22．support abundant network protocal: TCP/IP, HTTP, TCP, UDP, SMTP, FTP, DHCP, DNS, DDNS, NTP, UPNP, RTSP, and so on.
23．IE access, Audio/Video stream, TCP use the same port, easy to set on Router
24．Support UPNP port forwarding automatically
25. with PC client software, that can realize monitoring, control, center alarm at different place
For PT SPEED DOME
1. Continuous 360°pan, tilt turning 95°
2. 8pcs IR LEDs for Two groups of controlling
3. Presets:256; Address range:0-255
4. Cruising route:5,16 presets each route
5. Guarding point: duration adjustable limit point scan speed adjustable
6. Scan automatically: speed adjustable
7. protocol:Pelco-D Baud Rate:9600bps
8. IR distance :1-120m
9. IP66 Waterproof level
Technical parameters
Camera | Model | P01H9L4 |
Operating system | embedded Linux | |
Processor | Hi3516C | |
Image sensor | 1/2.8” 2 megapixel progressive sony 323 CMOS sensor | |
Minimum illumination | Color:0.1Lux, black and white 0 Lux | |
Lens | 20x ZOOM ,4.7-97mm zoom lens | |
Distance | 100m | |
Compression standard | Video compression | H.264 Main profile and Baseline profile adjustable |
Audio compression | G.726/G.711 (Default is G.711) | |
Video compression | 32Kbps-8Mbps, can self-defined, default is 6144Kbps | |
Image | video resolution | first stream: 1080P(1920*1080) and 720P(1280*720) optional |
sub stream: Q720(640*352) and QQ720P(320*176) optional | ||
Three Stream:QQ720P(320*176) | ||
JPEG code rate: Q720P(640*352) and QQ720P(320*176) (for mobile phone viewing) | ||
Video frame rate | 25fps(50HZ), 25fps(60HZ) | |
OSD | support OSD name and Time OSD (on and off available) | |
Image setting | Brightness, Contrast, Saturation, Exposure, Flip and Mirror are adjustable | |
Function | Storage | Support 8,16,32,64,128GB SD card |
Motion detection | can set 4 independent detection area (sensitivity is 1-100 adjustable) | |
Alarm linkage | sending pictures to named mailbox; upload pictures and video to FTP server; pictures and videos to SD Card | |
Network protocal | TCP/IP，HTTP，TCP，ICMP，UDP，ARP, IGMP，SMTP，FTP，DHCP，DNS，DDNS，NTP，UPNP，RTSP, and so on | |
Access protocal | support ONVIF, support purview check(default close purview check) | |
Port | Audio Input | built-in Microphone, 1CH Audio Input, support connect external MIC/pickup |
Audio Output | built-in speaker, 1CH Audio output, support connect external microphone or amplifier | |
Network port | 10Base-T/100Base-TX Ethernet interface | |
WIFI 802.11b/g/n wireless network(Option) | ||
common specification | Power supply | DC 12V, 1.6-2A |
Power consumption | 20W | |
Size | 4 inch | |
Operating temperature | -20 ~ +80 ℃ | |
Operating humidity | 10 ~ 95%RH |
